Sol Effect XT Paramotor Wing

£4,224.00

The new Effect XT paramotor wing   was developed for adventure lovers.

It doesn’t matter if the day is going to be long XC flights, freeriding or even competition, in the classic FAI modalities, this wing was created to face all kinds of challenges.

With the Effect XT, Sol Paragliders expands its number of wings and creates the XT series (extended technology), that is, the combination of all the technologies that the market offers without losing comfort and safety in piloting.

This combination of technologies provided the introduction of new features for piloting and increased performance.

Sol Paragliders has not forgotten the main thing: safety and ease of piloting. The set of piloting features are all close, highlighted and easy to use. All commands are executed normally without extra movements, they can be acted together according to the need and the compatible meteorological condition.

SKU: GN-022419PRWING Category:

Description

The new Effect XT paramotor wing   was developed for adventure lovers.

It doesn’t matter if the day is going to be long XC flights, freeriding or even competition, in the classic FAI modalities, this wing was created to face all kinds of challenges.

With the Effect XT, Sol Paragliders expands its number of wings and creates the XT series (extended technology), that is, the combination of all the technologies that the market offers without losing comfort and safety in piloting.

This combination of technologies provided the introduction of new features for piloting and increased performance.

Sol Paragliders has not forgotten the main thing: safety and ease of piloting. The set of piloting features are all close, highlighted and easy to use. All commands are executed normally without extra movements, they can be acted together according to the need and the compatible meteorological condition.

Effect XT – a world of possibilities




Certification



Inspection CertificateXXSXSsMLXL
Certification Number3478E3479E 3480E3481E3482E3483E
Load & Resistance TestCERTIF DGAC EFFECT XT



flight characteristics



With new construction techniques, we have a reduction in weight, volume and drag (Vectran competition lines).
Double command – allows for more open and flat curves or steeper curves with a smaller radius.
Tie rods – Developed for ease of handling.
Takeoff – easy inflation in a short space.
Landing – Extended ground effect facilitating the stop moment (Estoll) and less impact when touching the ground.
Use of Full Reflex technology reducing the possibility of collapses.
Speed ​​- Increased speed due to Reflex technology.
In short, a piece of equipment to satisfy the needs and demands of paramotor pilots who want more performance x ease of use x safety.






New Piloting Features



The Effect XT ‘s piloting features offer more precise piloting, supporting all styles of flight. The introduction of Performance Flaps (for better use of thermals) and a duo acceleration system (assisting in dynamic curves) creates the possibility for the pilot to work at minimum and maximum speed with safety and agility.

New 2D commands that expand dynamic movements and tighter curves in high-speed movements are part of the set of possibilities that the pilot has to adapt to the flight and objective.

High-tech materials like thinner threads and lighter fabric make for a flawless, easy takeoff. As far as performance is concerned, we still have more gliding performance and increased speed.






Technologies

The  EFFECT XT  combines our technologies for performance, safety and durability.
Constant Pressure (Shark Mouth)4 tie rods
Cross SplintsLaser cut
Hybrid MaterialsWeight distribution tapes
3d modelingmini ribs
flexible splintsGreatest Elongation designed
bow techreflex profile
double commandYield Flaps
High Tech MaterialsDuo Speed ​​System



Gallery








Technical Data

XXSXSsMLXL
cells
53
53
53
53
53
53
Real Area
17.12
18.42
19.53
21.61
23.80
26.10
m2
Actual Wingspan
9.7210.0810.3810.9211.4612.00
m
Actual Stretching
5.525.525.525.525.525.52
Projected Area
14.45
15.54
16.48
18.24
20.09
22.03
m2
Projected Wingspan
7.82
8.11
8.35
8.78
9.22
9.65
m
Designed Stretching
4.234.234.234.234.234.23
Diameter of Lines
0.6 – 0.7 – 0.9 – 1.0 – 1.1 – 1.2 – 1.6
mm
Height
623644662694726758
cm
Maximum Profile
216224231243255267
cm
Minimum Profile
626466697376
cm
Sail Weight
4
4.2
4.4
4.9
5.5
6
kg
Takeoff Weight
60-105
70-120
80-135
100-150
115-165
135-180
kg
Certification
DGACDGACDGACDGACDGACDGAC




Materials

Since 1991,  SOL  has been producing and accompanying the evolution of materials and products. Our experience leads us to carefully choose the materials used, guaranteeing great durability and a high level of safety. The  EFFECT XT is a SOL   paramotor wing manufactured in its own factory.

TopWTX 40 PU + Silicon 40 gr/sm – WTX 29 PU + Silicon 29 gr/sm
BottomWTX 40 PU + Silicon 40 gr/sm – WTX 29 PU + Silicon 29 gr/sm
profilesPro-Nyl High Tenacity Nylon rip-stop Hard finish 36 gr/sm
ReinforcementsNylon Maxthread Meada 2.5 mm
linesLiros Dyneema PPSLS 0.7 – 1.1 – 1.2 – 1.6 mm – Cousin Vectran 0.6 – 0.9 – 1.0 – 1.2 mm
carabinersAnsung Precision 20mm. 800 kg
risersPolyester Venus 19 mm. 1,600 kg
PulleysNylon Sol 12 mm / ISR 16 mm ball bearing






Downloads



ManualWarranty term
Line Planinfo





delivered with

Additional information

Weight6.0000 kg
